Hioki IM3533 - Perform Measurements with User-Defined Timing (Trigger Measurement)

4.2 Setting Basic Settings of Measurement Conditions
60
Triggering is the process of controlling the start and stop of recording by specific signals or conditions (crite-
ria). When recording is started or stopped by a specific signal, we say the trigger is "gapplied" or "triggering
occurs".
With this instrument, you can select the following two types of trigger.
4.2.5 Perform Measurements with User-defined Timing
(Trigger Measurement)
Internal Trigger
Trigger signals are automatically generated internally to repeat mea-
surement.
External trigger
Measurements are triggered by an external signal.
Manual measurement triggering is also available.
Procedure
LCR Measurement Screen LCR Basic Settings
1
Press .
2
LCR Basic Settings
