Hioki IM3533 - Checking Contact Defects and the Contact State (Contact Check Function)

4.5 Setting Application Settings
132
This functionality allows you to detect contact defects between the terminals (H
CUR
, H
POT
, L
CUR
, and L
POT
)
and the sample during 4-terminal measurement.
See Contact check error display (p. 360)
4.5.4 Checking Contact Defects and the Contact State
(Contact Check Function)
Procedure
LCR Measurement Screen LCR Application Settings
1
Press .
2
LCR Application Settings
3
Contact Check Settings
Select the timing at which to perform contact
check operation.
Disables the contact check function.
Performs a contact check before measur-
ing the sample.
Performs a contact check after measuring
the sample.
Performs a contact check before and after
measuring the sample.
