5.2 Setting Basic Settings of Measurement
166
The testing speed can be set. The slower the testing speed is, the more accurate are the results.
5.2.8 Setting the Measurement Speed
The waveform averaging function allows you to set the measurement speed at a higher level
of detail. When the waveform averaging function is enabled, speed settings are not avail-
able. Disable the waveform averaging function before setting the speed.
See "5.3.2 Setting the Detection Signal Waveform Averaging Count (Waveform Averaging Function)"
(p. 173)
Procedure
ANALYZER Measurement Screen ANALYZER Basic Settings
1
Press .
ANALYZER Basic Settings
2
To select the measurement speed.
4
3
Measurement speed varies with the measurement
conditions.
The speeds given in the table relate to the case of |Z|
only being displayed.
See "About Measurement Times and Measurement
Speed" (p. 350)
Press to close the setting screen.
Performs high-speed measurement.
This is the normal measurement speed.
Measurement precision improves.
Measurement accuracy is better than
SLOW.
Measurement Speed Setting
To Next Page
