Hioki IM3533 - Saving Measurement Results (Memory Function)

5.3 Application Settings
179
5
Chapter 5 ANALYZER Function (IM3533-01)
You can save the measurement results inside the instrument. (Up to 32,000 items) The saved measurement
results can be saved to a USB flash drive.
They can also be acquired using a communication command. Memory function settings apply to
mode, mode, and mode.
When the memory function is set to "IN" in or mode, it will be set to "ON" in mode.
The items saved to memory are in accordance with the
:MEASure:VALid setting.
For details on how to acquire the saved measurement results or set
:MEASure:VALid, refer to the
included LCR Application Disk.
5.3.5 Saving Measurement Results (Memory function)
Saving Measurement Values
Procedure
ANALYZER Application Settings
1
ANALYZER Measurement Screen
Press .
2
ANALYZER Application Settings
