Appendix
Appendix10 Rack Mounting
A15
Rack mounting brackets can be attached to the instrument.
Appendix10Rack Mounting
Observe the following precautions regarding the mounting screws to avoid instru-
ment damage and electric shock accidents.
• When installing the Rack Mounting Plate, the screws must not intrude more than 6
mm into either side of the instrument.
• When removing the Rack Mounting Plate to return the instrument to stand-alone use,
replace the same screws that were installed originally. (Feet: M3
× 8 mm, Sides: M4 × 6 mm)
Rack Mounting Plate (JIS)
Spacer (Two Required)
Rack Mounting Plate (EIA)
To Next Page
