10.3 Self Checks (Self Diagnosis)
265
10
Chapter 10 Setting the SYSTEM
You can check the display screens of the instrument.
You can check the touch panel.
10.3 Self Checks (Self Diagnosis)
Panel Test
LCR Measurement Screen
1
Self Checks
Procedure
You can check the touch panel in mode, mode, or mode.
3
Panel Test
Press the keys displayed on the screen.
If the pressed keys are highlighted and the green
appears, the touch panel is working properly.
Perform panel compensation (p. 266) if they are not
highlighted or the red appears.
If there is still problem after performing panel calibration,
the panel may be malfunctioning. Contact your autho-
rized Hioki distributor or reseller.
To Next Page
