Hioki IM3533 - Checking Contact Defects and the Contact State (Contact Check Function)

5.3 Application Settings
177
5
Chapter 5 ANALYZER Function (IM3533-01)
This functionality allows you to detect contact defects between the terminals (H
CUR
, H
POT
, L
CUR
, and L
POT
)
and the sample during 4-terminal measurement.
5.3.4 Checking Contact Defects and the Contact State
(Contact Check Function)
ANALYZER Application Settings
1
ANALYZER Measurement Screen
Procedure
Press .
2
ANALYZER Application Settings
3
Contact Check Settings
Select the timing at which to perform contact
check operations.
Disables the contact check function.
Performs a contact check before measuring the
sample.
Performs a contact check after measuring the
sample.
Performs a contact check before and after
measuring the sample.
