5.2 Setting Basic Settings of Measurement
169
5
Chapter 5 ANALYZER Function (IM3533-01)
For the DC bias setting, set the DC bias value for when sweep measurement is performed.
If the DC bias is set, a DC signal can be superimposed on the measurement signal during capacitor measure-
ment.
5.2.11 Setting the DC Bias
Procedure
Press .
ANALYZER Measurement Screen ANALYZER Basic Settings
1
ANALYZER Basic Settings
2
3
DC Bias Setting
Select ON/OFF for the DC bias.
Disables the DC bias setting.
Enables the DC bias setting.
Press this button when using an external
DC bias unit.
The DC bias will be set to ON, and the bias
value will be set to 0.00 V.
To Next Page
