The following table shows the initial settings of the instrument.
Appendix12 Initial Settings Table
Yes: Available/ No: Unavailable/ : The same as the initial settings
Setting Items Initial setting
instru-
ment
RESET
operati
on full
reset
*RST :PRESet
Return to
initial
settings
when
power is
turned
on
Panel save/ Load
*1
File
save/
Load
LCR
mode
ANALY
ZER
mode
*2
TRAN
SFOR
MER
mode
Measurement mode LCR  No Yes Yes Yes Yes
LCR mode measurement parameter Z/OFF//OFF No Yes Yes Yes Yes
Magnification display OFF  No No No No Yes
Basic settings
(LCR mode/
TRANSFORMER
mode)
Measurement frequency 1 kHz No Yes Yes Yes Yes
Measurement
signal level
Mode V No Yes Yes Yes Yes
V 1.000 V No Yes Yes Yes Yes
CV 1.000 V No Yes Yes Yes Yes
CC 10.00 mA No Yes Yes Yes Yes
Limit
ON/OFF OFF No Yes Yes Yes Yes
Current limit value 100.00 mA No Yes Yes Yes Yes
Voltage limit value 5.00 V No Yes Yes Yes Yes
DC bias
(TRANSFORMER
mode: None)
ON/OFF OFF No Yes Yes No Yes
Bias value 0.00 V No Yes Yes No Yes
Trigger mode
(TRANSFORMER mode: None)
INT
(Internal Trigger)
 No Yes Yes No Yes
Measurement range
Mode AUTO No Yes Yes Yes Yes
AUTO range control
function
100 m/
100 M
 No Yes Yes Yes Yes
Range 100 No Yes Yes Yes Yes
Judgment synchroni-
zation setting
OFF No Yes Yes Yes Yes
LOW Z OFF No Yes Yes Yes Yes
Measurement speed MED  No Yes Yes Yes Yes
Number of times for average 1  No Yes Yes Yes Yes
Trigger delay 0.0000 s No Yes Yes Yes Yes
Trigger synchronous
output
ON/OFF OFF No Yes Yes Yes Yes
Trigger time 0.0010 s No Yes Yes Yes Yes
AC range
synchroni
zation
function *3
Measurement speed MED No Yes No Yes Yes
Number of times for average 1 No Yes No Yes Yes
Trigger delay 0.0000 s No Yes No Yes Yes
Trigger synchronous
output
ON/OFF OFF No Yes No Yes Yes
Trigger time 0.0010 s No Yes No Yes Yes
