Appendix
Appendix12 Initial Settings Table
A19
LCR mode
DC resistance
measurement
Temperature
correction
ON/OFF OFF No Yes No No Yes
Reference
temperature
20.0°C No Yes No No Yes
Temperature
coefficient
3930 ppm No Yes No No Yes
DC delay 0.0000 s No Yes No No Yes
ADJ delay 0.0030 s No Yes No No Yes
Line frequency 60 Hz No Yes No No Yes
Measurement range
Mode AUTO No Yes No No Yes
AUTO range limit
function
100 m/
100 M
No Yes No No Yes
Range 100 No Yes No No Yes
Judgment synchroni-
zation setting
OFF No Yes No No Yes
LOW Z OFF No Yes No No Yes
Measurement speed MED No Yes No No Yes
Number of times for average 1 No Yes No No Yes
DC range
synchronization
function
*3
Measurement speed MED No Yes No No Yes
Number of times for average 1 No Yes No No Yes
Application
settings
(for all modes)
Judgment mode OFF No Yes No Yes Yes
Memory
OFF/IN/ON OFF No Yes Yes Yes Yes
Number of memory
items
1000 No Yes Yes Yes Yes
Range synchronization function OFF  No Yes No Yes Yes
Waveform averaging
function
ON/OFF OFF No Yes Yes Yes Yes
No. of waveform aver-
ages for each frequen-
cy band
No. of MED
waveform averages
No Yes Yes Yes Yes
Judgment result
Delay between judg-
ment results and EOM
0.0000 s No No No No Yes
Reset ON No No No No Yes
IO trigger
ENABLE ON No No No No Yes
Edge DOWN No No No No Yes
IO EOM
Mode HOLD No No No No Yes
EOM
output time 0.0050 s No No No No Yes
HIGH-Z Reject
ON/OFF OFF No Yes Yes Yes Yes
Judgment reference
value
1000% No Yes Yes Yes Yes
Contact check
Timing OFF No Yes Yes Yes Yes
Threshold 2 No Yes Yes Yes Yes
Display digits 6/6/6/6 No Yes No Yes Yes
Backlight ON/OFF ON  No No No No Yes
Beep sound
Judgment result NG No Yes Yes Yes Yes
Key ON No No No No Yes
Beep tone C No No No No Yes
Key-lock
ON/OFF OFF No No No No Yes
Passcode 3533 No No No No Yes
LCR mode
comparator
Mode ABS/ABS  No Yes No No Yes
Absolute value mode
Upper limit value OFF/OFF No Yes No No Yes
Lower limit value OFF/OFF No Yes No No Yes
Percent mode
Deviation percent-
age mode
Reference value 1.0000 k/ 10.0000 No Yes No No Yes
Upper limit value OFF/OFF No Yes No No Yes
Lower limit value OFF/OFF No Yes No No Yes
Yes: Available/ No: Unavailable/ : The same as the initial settings
Setting Items Initial setting
instru-
ment
RESET
operati
on full
reset
*RST :PRESet
Return to
initial
settings
when
power is
turned
on
Panel save/ Load
*1
File
save/
Load
LCR
mode
ANALY
ZER
mode
*2
TRAN
SFOR
MER
mode
