Appendix12 Initial Settings Table
A20
BIN
Mode ABS/ABS No Yes No No Yes
Absolute value mode
Upper limit value OFF/OFF No Yes No No Yes
Lower limit value OFF/OFF No Yes No No Yes
Percent mode
Deviation percent-
age mode
Reference value 1.0000 k/ 10.0000 No Yes No No Yes
Upper limit value OFF/OFF No Yes No No Yes
Lower limit value
OFF/OFF No Yes No No Yes
Basic settings
(ANALYZER
mode)
Sweep parameters Z -
 No No Yes No Yes
Trigger REPEAT No No Yes No Yes
Display timing REAL No No Yes No Yes
Trigger delay 0.0000 s No No Yes No Yes
Normal sweep
Sweep start value 1.0000 kHz No No Yes No Yes
Sweep end value 100.00 kHz No No Yes No Yes
No. of points 201 No No Yes No Yes
Measurement point
setting method
LOG No No Yes No Yes
Sweep signal
1.000 V
(V mode)
 No No Yes No Yes
Measurement range AUTO No No Yes No Yes
Measurement speed MED No No Yes No Yes
Averaging count OFF No No Yes No Yes
Point delay 0.0000 s No No Yes No Yes
DC bias
ON/OFF OFF No No Yes No Yes
Bias value 0 V No No Yes No Yes
Measurement parameters (TRANSFORMER mode) Ls No No No Yes Yes
Calculation parameters (TRANSFORMER mode) N No No No Yes Yes
TRANSFORMER
mode
Comparator
Mode ABS  No No No Yes Yes
Absolute value mode
Upper limit value OFF  No No No Yes Yes
Lower limit value OFF No No No Yes Yes
Percent mode
Deviation percent-
age mode
Reference value 10.0000  No No No Yes Yes
Upper limit value OFF  No No No Yes Yes
Lower limit value OFF No No No Yes Yes
CONTINUOUS
measurement
Display timing REAL No No No No Yes
Open circuit
compensation
Compensation mode OFF 
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
Correction value
G Correction value 0.000 ns 
No
C
hange
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
B Correction value 0.000 ns 
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
Compensation range
limit function
DC ON 
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
MIN 20.000 Hz 
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
MAX 200.00 kHz 
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
Short circuit
compensation
Compensation mode OFF 
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
Correction value
R Correction value 0.00m
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
X Correction value 0.00m
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(A
DJ)
Yes
Compensation range
limit function
DC ON 
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
MIN 20.000 Hz 
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
MAX 200.00 kHz 
No
Change
No
Yes
(ADJ)
Yes
(ADJ)
Yes
(ADJ)
Yes
Yes: Available/ No: Unavailable/ : The same as the initial settings
Setting Items Initial setting
instru-
ment
RESET
operati
on full
reset
*RST :PRESet
Return to
initial
settings
when
power is
turned
on
Panel save/ Load
*1
File
save/
Load
LCR
mode
ANALY
ZER
mode
*2
TRAN
SFOR
MER
mode
