4.2 Setting Basic Settings of Measurement Conditions
70
• The ranges that can be set vary with the frequency. (p. 67)
• When only, D, or Q has been set, functionality is used.
• Because the phase angle cannot be calculated for some combinations of parameters, the
range is determined from ideal values. For more information, see the table below.
See "Appendix1 Measurement Parameters and Calculation Formula"(p. A1)
3
Range Setting
Turn the judgment synchronization setting on
or off.
Disables the judgment synchronization
setting.
Enables the judgment synchronization set-
ting.
4
Press to close the setting screen.
Parameter combination conditions for the judgment synchronization setting
AC OFF Z Y Rs Rp X G B Ls Lp Cs Cp  D Q
OFF
×
 
        
× × ×
Z
  
        
  
Y
  
        
  
Rs
           
  
Rp
           
  
X
           
  
G
           
  
B
           
  
Ls
           
  
Cs
           
  
Cp
           
  

×
          
× × ×
D
×
          
× × ×
Q
×
          
× × ×
The third parameter
The first parameter
×
Invalid setting (treated as range)
 Set from ideal value since phase angle cannot be calculated.

Setting prohibited.
