103
Figure 92 Creating an SNMP view (2)
6. Configure the parameters as described in Table 34.
7. Click Add to add the rule into the list at the lower part of the page.
8. Repeat steps 6 and 7 to add more rules for the SNMP view.
9. Click Apply.
To cancel the view, click Cancel.
Table 34 Configuration items
Item Descri
View Name Set the SNMP view name.
Rule
Select to exclude or include the objects in the view range determined by the MIB
subtree OID and subtree mask.
MIB Subtree OID
Set the MIB subtree OID (such as 1.4.5.3.1) or name (such as system).
MIB subtree OID identifies the position of a node in the MIB tree, and it can uniquely
identify a MIB subtree.
Subtree Mask
Set the subtree mask, a hexadecimal string. Its length must be an even number in the
range of 2 to 32.
If no subtree mask is specified, the default subtree mask (all Fs) will be used for
mask-OID matching.
Adding rules to an SNMP view
1. Select Device > SNMP from the navigation tree.
2. Click the View tab.
The page in Figure 90 appears.
3. Click the icon of the target view.
The Add rule for the view ViewDefault window appears.
