tion
Please select port(s)
Specify the ports to be configured with rate limit.
Click the ports to be configured with rate limit in the port list. You can select
one or more ports.
Configuring priority mapping tables
1. Select QoS > Priority Mapping from the navigation tree.
Figure 496 Configuring priority mapping tables
2. Configure a priority mapping table as described in Table 159.
3. Click Apply.
Table 159 Configuration items
Item Descri
tion
Mapping Type
Select the priority mapping table to be configured, which can be CoS to
DSCP, CoS to Queue, DSCP to CoS, DSCP to DSCP, or DSCP to Queue.
Input Priority Value
Set the output priority value for an input priority value.
Output Priority Value
Restore
Click Restore to display the default settings of the current priority mapping
table on the page.
To restore the priority mapping table to the default, click Apply.
Configuring priority trust mode on a port
1. Select QoS > Port Priority from the navigation tree.
