HP 830 Series User Manual

480
3. Add a class as described in Table 149.
4. Click Create.
Table 149 Configuration items
Item Descri
p
tion
Classifier Name
Specify a name for the classifier to be added.
Some devices have their own system-defined classifiers. The classifier name you
specify cannot overlap with system-defined ones. The system-defined classifiers
include: default-class, ef, af1, af2, af3, af4, ip-prec0, ip-prec1, ip-prec2, ip-prec3,
ip-prec4, ip-prec5, ip-prec6, ip-prec7, mpls-exp0, mpls-exp1, mpls-exp2, mpls-exp3,
mpls-exp4, mpls-exp5, mpls-exp6, and mpls-exp7.
Operator
Specify the logical relationship between rules of the classifier.
• and—Specifies the relationship between the rules in a class as logic AND. The
device considers that a packet belongs to a class only when the packet matches all
the rules in the class.
• or—Specifies the relationship between the rules in a class as logic OR. The device
considers that a packet belongs to a class as long as the packet matches one of the
rules in the class.
Configuring classification rules
1. Select QoS > Classifier from the navigation tree.
2. Click Setup to enter the page for setting a class.
