481
Figure 487 Configuring classification rules
3. Configure classification rules for a class as described in Table 150.
4. Click Apply.
Table 150 Configuration items
Item Descri
tion
Please select a classifier
Select an existing classifier in the list.
Any
Define a rule to match all packets.
Select the box to match all packets.
DSCP
Define a rule to match DSCP values.
If multiple rules are configured for a class, the new configuration does not
overwrite the previous.
You can configure up to eight DSCP values at a time. If multiple identical DSCP
values are specified, the system considers them as a single value. The
relationship between different DSCP values is OR. After configuration, all the
DSCP values are arranged in ascending order automatically.
