Creating a mirroring group
1. Select Device > Port Mirroring from the navigation tree.
2. Click the Create tab.
The page for creating a mirroring group appears.
Figure 51 Creating a mirroring group
3. Create the mirroring group as described in Table 14.
4. Click Apply.
Table 14 Configuration items
Item Descri
p
tion
Mirroring Group ID ID of the mirroring group to be created, in the range of 1 to 5.
Type Set the type of the mirroring group to be added to Local.
Configuring ports for a mirroring group
1. Select Device > Port Mirroring from the navigation tree.
2. Click the Modify Port tab.
The page for configuring ports for a mirroring group appears.
