WRR
Setup
WRR
Enable or disable the WRR queue scheduling mechanism on selected ports. The
following options are available:
• Enable—Enables WRR on selected ports.
• Not Set—Restores the default queuing algorithm on selected ports.
Queue
Select the queue to be configured.
A queue ID ranges from 0 to n-1 (n is the maximum number of queues on an
interface and varies by device).
Group
Specify the group the current queue is to be assigned to.
This list is available after you select a queue ID. The following groups are available
for selection:
• SP—Assigns a queue to the SP group.
• 1—Assigns a queue to WRR group 1.
• 2—Assigns a queue to WRR group 2.
Weight
Set a weight for the current queue.
This list is available when group 1 or group 2 is selected.
Please select port(s)
Click to select ports to be configured with queuing on the chassis front panel.
Configuring rate limit on a port
1. Select QoS > Line rate from the navigation tree.
2. Click the Setup tab to enter the rate limit configuration page.
