Configure IPv4
address
DHCP Configure how the VLAN interface obtains an IPv4 address:
• DHCP—Select this option to obtain an IPv4 address for the VLAN
interface through DHCP.
• BOOTP—Select this option to obtain an IPv4 address for the VLAN
interface through BOOTP.
• Manual—Select this option to manually specify an IPv4 address and
the mask length for the VLAN interface.
BOOTP
Manual
IPv4
address
Specify an IPv4 address and mask length for the VLAN interface. Dotted
decimal notation is supported for the mask length field.
These two fields are configurable only if Manual is selected.
MaskLen
GateWay Specify the gateway IP address for the device.
Configure IPv6
link-local address
Auto Configure how the VLAN interface obtains an IPv6 link-local address.
• Auto—Select this option to have the device automatically generate a
link-local address based on the link-local address prefix (FE80::/64)
and the link layer address of the interface.
• Manual—Select this option to manually assign an IPv6 link-local
address to the interface.
Manual
IPv6
address
Specify an IPv6 link-local address for the VLAN interface.
This field is configurable only if Manual is selected. The address prefix
must be FE80::/64.
Finishing configuration wizard
After finishing the management IP address configuration, click Next.
The page displays your configurations. Review the configurations. If you want to modify the settings, click
Back to go back to the page. Click Finish to confirm your settings. The system then performs the
configurations.
