HP 830 Series User Manual

484
3. Add a traffic behavior as described in Table 151.
4. Click Create.
Table 151 Configuration items
Item Descri
p
tion
Behavior name
Specify a name for the behavior to be added.
Some devices have their own system-defined behaviors. The behavior name you
specify cannot overlap with system-defined behaviors. The system-defined behaviors
include ef, af, and be.
Configuring traffic mirroring and traffic redirecting
for a traffic behavior
1. Select QoS > Behavior from the navigation tree.
2. Click Port Setup to enter the port setup page for a traffic behavior.
Figure 489 Port setup page for a traffic behavior
3. Configure traffic mirroring and traffic redirecting as described in Table 152.
4. Click Apply.
Table 152 Configuration items
Item Descri
p
tion
Please select a behavior Select an existing behavior in the list.

HP 830 Series Specifications

General

Brand	HP
Model	830 Series
Category	Switch
Language	English
