tion
Time Range Name
Set the name for the time range.
Periodic Time Range
• Start Time—Set the start time of the periodic time range.
• End Time—Set the end time of the periodic time range. The end time must be
later than the start time.
• Sun, Mon, Tue, Wed, Thu, Fri, and Sat—Select the day or days of the week on
which the periodic time range is valid. You can select any combination of the
days of the week.
Absolute Time Range
• From—Set the start time and date of the absolute time range. The time of the
day is in the hh:mm format (24-hour clock), and the date is in the
MM/DD/YYYY format.
• To—Set the end time and date of the absolute time range. The time of the day
is in the hh:mm format (24-hour clock), and the date is in the MM/DD/YYYY
format. The end time must be later than the start time.
NOTE:
You can define both a periodic time range and an absolute time ran
This compound time range recurs on the day or days of the week only within the specified period.
Adding an IPv4 ACL
1. Select QoS > ACL IPv4 from the navigation tree.
2. Click the Create tab to enter the IPv4 ACL configuration page.
Figure 469 Adding an IPv4 ACL
3. Add an IPv4 ACL as described in Table 136.
4. Click Apply.
