tion
Accounting
Configure the traffic accounting action.
Select the Accounting box and select Enable or Disable in the
following list to enable/disable the traffic accounting action.
Adding a policy
1. Select QoS > QoS Policy from the navigation tree.
2. Click the Create tab to enter the page for adding a policy.
Figure 491 Adding a policy
3. Add a policy as described in Table 154.
4. Click Create.
Table 154 Configuration items
Item Descri
tion
Policy Name
Specify a name for the policy to be added.
Some devices have their own system-defined policies. The policy name you specify
cannot overlap with system-defined policies. The system-defined policy is the policy
default.
Configuring classifier-behavior associations for the
policy
1. Select QoS > QoS Policy from the navigation tree.
2. Click Setup to enter the page for setting a policy.
