tion
Please select a behavior
Select an existing behavior in the list.
CAR
Enable/Disable Enable or disable CAR.
CIR Set the committed information rate (CIR), the average traffic rate.
CBS
Set the committed burst size (CBS), number of bytes that can be sent
in each interval.
Red
Discard
Set the action to perform for exceeding packets.
After selecting the Red box, you can select one of the following
options:
• Discard—Drops the exceeding packet.
• Pass—Permits the exceeding packet to pass through.
Pass
Remark
IP Precedence
Configure the action of marking IP precedence for packets.
Select the IP Precedence box and then select the IP precedence
value to be marked for packets in the following list. Select Not Set to
cancel the action of marking IP precedence.
Dot1p
Configure the action of marking 802.1p priority for packets.
Select the Dot1p box and then select the 802.1p priority value to be
marked for packets in the following list. Select Not Set to cancel the
action of marking 802.1p priority.
Local Precedence
Configure the action of marking local precedence for packets.
Select the Local Precedence box and then select the local
precedence value to be marked for packets in the following list.
Select Not Set to cancel the action of marking local precedence.
DSCP
Configure the action of marking DSCP value for packets.
Select the DSCP box and then select the DSCP value to be marked
for packets in the following list. Select Not Set to cancel the action of
marking DSCP value.
Queue
EF
Max Bandwidth
Configure the minimum guaranteed bandwidth for Assured
Forwarding (AF).
Percent Configure the percent of available bandwidth for AF.
WFQ
Configure WFQ for the default class by entering the total number of
fair queues, which must be the power of two.
Filter
Configure the packet filtering action.
After selecting the Filter box, select one item from the following list:
To Next Page
