Configuring the flow interval
With the flow interval module, you can view the number of packets and bytes sent and received by a port
over the specified interval.
Setting the traffic statistics generating interval
1. Select Device > Flow Interval from the navigation tree.
2. Click the Interval Configuration tab.
The page for setting the interval for generating port traffic statistics appears.
Figure 63 Setting the traffic statistics generating interval
3. Set the traffic statistics generating interval as described in Table 18.
4. Click Apply.
Table 18 Configuration items
Item Remarks
Interval for generating traffic statistics
Set the interval for generating port traffic statistics.
Select ports
Select ports from the chassis front panel to apply the interval to them.
Displaying port traffic statistics
To display port traffic statistics, select Device > Flow Interval from the navigation tree. The Port Traffic
Statistics page appears by default.
