Configuring and displaying clients' IP-to-MAC bindings
1. Select Network > DHCP from the navigation tree and click DHCP Relay.
2. In the User Information field, click User Information to view static and dynamic bindings, as shown
in Figure 253.
Figure 253 Displaying clients' IP-to-MAC bindings
3. Click Add to enter the page as shown in Figure 254.
Figure 254 Creating a static IP-to-MAC binding
4. Configure the static IP-to-MAC binding as described in Table 93.
5. Click Apply.
Table 93 Configuration items
Item Descri
p
tion
IP Address Enter the IP address of a DHCP client.
MAC Address Enter the MAC address of the DHCP client.
Interface Name
Select the Layer 3 interface connected with the DHCP client.
IMPORTANT:
The interface of a static binding entry must be configured as a DHCP relay agent.
Otherwise, address entry conflicts may occur.
