Table 136 Configuration items
Item Descri
p
tion
ACL Number Set the number of the IPv4 ACL.
Match Order
Set the match order of the ACL. Available values are:
• Config—Packets are compared against ACL rules in the order that the rules are
configured.
• Auto—Packets are compared against ACL rules in the depth-first match order.
Configuring a rule for a basic IPv4 ACL
1. Select QoS > ACL IPv4 from the navigation tree.
2. Click the Basic Setup tab to enter the rule configuration page for a basic IPv4 ACL.
Figure 470 Configuring an basic IPv4 ACL
3. Configure a rule for a basic IPv4 ACL as described in Table 137.
4. Click Add.
Table 137 Configuration items
Item Descri
p
tion
ACL
Select the basic IPv4 ACL for which you want to configure rules.
Available ACLs are basic IPv4 ACLs.
