Destination IP Address
Destination IP address and subnet mask of the IPv4 route..
Mask
Protocol Protocol that discovered the IPv4 route.
Preference
Preference value for the IPv4 route.
The smaller the number, the higher the preference.
Next Hop Next hop IP address of the IPv4 route.
Interface
Outgoing interface of the IPv4 route. Packets destined for the specified
network segment are sent out of the interface.
Creating an IPv4 static route
1. Select Network > IPv4 Routing from the navigation tree.
2. Click the Create tab.
The page for configuring IPv4 static route appears.
Figure 233 Creating an IPv4 static route
3. Create an IPv4 static route as described in Table 84.
4. Click Apply.
Table 84 Configuration items
Item Descri
Destination IP Address
Enter the destination host or network IP address, in dotted decimal notation.
Mask
Enter the mask of the destination IP address.
You can enter a mask length or a mask in dotted decimal notation.
