Aggregation interface
Type and ID of the aggregate interface.
Bridge-Aggregation indicates a Layer 2 aggregate interface.
Link Type Type of the aggregate interface, which can be static or dynamic.
Partner ID ID of the remote device, including its LACP priority and MAC address.
Selected Ports
Number of Selected ports in each link aggregation group (Only Selected ports
can transmit and receive user data).
Standby Ports
Number of Unselected ports in each link aggregation group (Unselected ports
cannot transmit or receive user data).
Member Port
A member port of the link aggregation group corresponding to the selected
aggregate interface.
State Select state of a member port: Selected or Unselected.
Reason for being Unselected
Reason why the state of a member port is Unselected. For a selected member
port, this field is displayed as a hyphen (-).
Setting LACP priority
1. Select Network > LACP from the navigation tree.
2. Click Setup.
Figure 173 The Setup tab
