Device Location
Device location, which you can configure on the page you enter by
selecting Device > SNMP > Setup.
Contact Information
Contact information, which you can configure on the page you enter
by selecting Device > SNMP > Setup.
SerialNum Serial number of the device.
Software Version Software version of the device.
Hardware Version Hardware version of the device.
Bootrom Version Boot ROM version of the device.
Running Time System up time.
System resource state
Table 7 Field description
Field Descri
CPU Usage
Real-time CPU usage.
Memory Usage
Real-time memory usage and the total memory size.
Temperature Temperature of the device.
Recent system logs
Table 8 Field description
Field Descri
Time Time when the system logs are generated.
Level Severity of the system logs.
Description Description for the system logs.
The System Information page shows up to five of the most recent system logs about the login and logout
events.
For more system logs, click More to enter the Log List page. You can also enter this page by selecting
Device > Syslog. For more information, see "Device."
Displaying device information
Select Summary from the navigation tree, and click the Device Information tab to enter the page that
displays the device port information. Hover the cursor over a port to view the port details, including the
port name, type, speed, utilization, status, and aggregation group number, as shown in Figure 22. F
or
the description about the port number and its color, see Figure 22.
Y
ou can also select the interval for refreshing the device information in the Refresh Period list.
• If you select a certain period, the system refreshes the information at the specified interval.
