Interface Name Select the name of the interface on which the history entry is created.
Buckets Granted
Set the capacity of the history record list corresponding to this history entry (the
maximum number of records that can be saved in the history record list).
If the current number of the entries in the table has reached the maximum number, the
system deletes the earliest entry to save the latest one. The statistics include total
number of received packets on the current interface, total number of broadcast
packets, and total number of multicast packets in a sampling period.
Interval Set the sampling period.
Owner Set the owner of the entry.
Configuring an event entry
1. Select Device > RMON from the navigation tree.
2. Click the Event tab.
The Event page appears.
Figure 72 Event page
3. Click Add.
The page for adding an event entry appears.
Figure 73 Adding an event entry
4. Configure an event entry as described in Table 26.
