HP 830 Series User Manual

134
Figure 132 Creating a VLAN interface
3. Configure the VLAN interface as described in Table 43.
4. Click Apply.
Table 43 Configuration items
Item Descri
p
tion
Input a VLAN ID:
Enter the ID of the VLAN interface to be created. Before creating a VLAN interface,
make sure the corresponding VLAN exists.
Configure
Primary
IPv4
Address
DHCP Configure the way in which the VLAN interface gets an IPv4 address.
Allow the VLAN interface to get an IP address automatically by selecting the DHCP or
BOOTP option. Otherwise, select the Manual option to manually assign the VLAN
interface an IP address. In the latter case, you must set the mask length or enter a mask
in dotted decimal notation format.
BOOTP
Manual
IPv4
Address
Configure an IPv4 address for the VLAN interface.
This field is available after you select the Manual option.
Mask
Length
Set the subnet mask length (or enter a mask in dotted decimal notation format).
This field is available after you select the Manual option.
Configure
IPv6 Link
Local
Address
Auto
Configure the way in which the VLAN interface gets an IPv6 link-local address.
Select the Auto or Manual option:
• Auto—The device automatically assigns a link-local address to the VLAN interface
based on the link-local address prefix (FE80::/64) and the link-layer address of the
VLAN interface.
• Manual—Requires manual assignment. If you select this option, set an IPv6
address.
Manual
IPv6
Address
Configure an IPv6 link-local address for the VLAN interface.
This field is available after you select the Manual option. The prefix of the IPv6
link-local address you enter must be FE80::/64.
