Figure 161 MST region
2. Click Modify to enter the page for configuring MST regions.
Figure 162 Configuring an MST region
3. Configure the MST region information as described in Table 55, and click Apply.
4. Click Activate.
Table 55 Configuration items
Item Descri
tion
Region Name
MST region name.
The MST region name is the bridge MAC address of the device by default.
Revision Level
Revision level of the MST region.
Manual (Instance ID and VLAN
ID)
Manually add VLAN-to-MSTI mappings. Click Apply to add the
VLAN-to-MSTI mapping entries to the list.
Modulo
The device automatically maps 4094 VLANs to the corresponding MSTIs
based on the modulo value.
