tion
[FORWARDING]
The port is in forwarding state, so the port learns MAC addresses and forwards
user traffic.
[LEARNING]
The port is in learning state, so the port learns MAC addresses but does not
forward user traffic.
[DISCARDING]
The port is in discarding state, so the port does not learn MAC addresses or
forward user traffic.
[DOWN] The port is down.
Port Protocol Indicates whether STP is enabled on the port.
Port Role
Role of the port, which can be Alternate, Backup, Root, Designated, Master, or
Disabled.
Port Priority Priority of the port.
Port Cost(Legacy)
Path cost of the port. The field in the bracket indicates the standard used for port
path cost calculation, which can be legacy, dot1d-1998, or dot1t. Config
indicates the configured value, and Active indicates the actual value.
Desg. Bridge/Port
Designated bridge ID and port ID of the port.
The port ID displayed is insignificant for a port that does not support port priority.
