208
Figure 186 The Neighbor Information tab
Table 75 Field description
Field Descri
p
tion
Chassis type
Chassis ID type:
Chassis component.
Interface alias.
Port component.
MAC address.
Network address.
Interface name.
Locally assigned, or the local configuration.
Chassis ID
Chassis ID depending on the chassis type, which can be a MAC address of
the device.
Port ID type
Port ID type:
Interface alias.
Port component.
MAC address.
Network address.
Interface name.
Agent circuit ID.
Locally assigned, or the local configuration.
Port ID Port ID value.
System capabilities supported
Primary network function of the system:
Repeater.
Bridge.
Router.
System capabilities enabled
Network function enabled on the system:
Repeater.
Bridge.
Router.
