314
Figure 305 802.1X configuration on a port
3. Configure 802.1X features on a port as described in Table 100.
4. Click Apply.
Table 100 Configuration items
Item Descri
Port
Select a port where you want to enable 802.1X. Only ports not enabled with 802.1X
authentication are available.
NOTE:
802.1X is mutually exclusive with link aggregation and service loopback group
configuration on a port.
Port Control
Select an access control method for the port, which can be MAC Based or Port Based.
NOTE:
To use both 802.1X and portal authentication on a port, you must select MAC Based.
Port Authorization
Select a port authorization state for 802.1X.
Options include:
• Auto—Places the port initially in the unauthorized state to allow only EAPOL
packets to pass. After a user passes authentication, this option sets the port in the
authorized state to allow access to the network.
• Force-Authorized—Places the port in the authorized state, enabling users on the
port to access the network without authentication.
• Force-Unauthorized—Places the port in the unauthorized state, denying any access
requests from users on the port.
Max Number of Users Set the maximum number of concurrent 802.1X users on the port.
