3.9 Gateway Parameter Configuration Tool
A3-157
ME0384-4A
[GW parameters 3]
• Delay time of driver reclosing : Sets the delay time (interval) when sequentially
supplying power to each axis of the driver unit.
It is used for the purpose of reducing inrush current
by shifting the timing of power supplied to each axis.
The initial value for the latency is 5ms for each axis.
However, the minimum latency of the 200V driver unit
is 50ms. Setting to a value less than 50ms should
automatically be pulled up to 50ms.
Also, for the EC connection unit, the release timing of
the drive cutoff circuit for each unit (four axes) should
get misaligned.
•
Number of power supply units connected
: Sets the number of IAI power supply units (Model:
PSA-24) that are connected to the gateway unit.
Up to 5 units can be connected.
• Power supply unit monitor type : Select the monitoring item for the IAI power supply
unit (PSA-24).
One item of those in the following table can be
monitored.
To Next Page
