IAI Rcon User Manual

2.2. Wiring
B2-14
ME0384-4A
Chapter 2 Mounting and Wiring
Startup Section
● Connection between 200V AC Servo-motor Actuator and 200V Driver Unit
● Connection between ELECYLINDER and EC Connection Unit
RCON System
200V
Driver Unit
RCON
-SC
Insert till end
Insert till end
Insert until it clicks
Insert until it clicks
Actuator
A
ctuator side
Encoder cable
Actuator side
Encoder
cable
Encoder cable
CB
-***-P(L)A***
M
otor cable
CB
-***-MA***
Clamp Filter
Recommended to be Installed
ZCAT3035-1330
Insert until it
clicks
Elecylinder
EC Connection Unit
Cable
RCON System
EC Connection Unit
RCON-EC
Elecylinder side
Insert until it
clicks
Controller side
EC
Connection Unit Cable
•
Standard Connector Cable Model Code
:
CB-REC-PWBIO***-RB
•
4-way Connector Cable Model Code:
CB-REC2-PWBIO***-RB
Connection
example
Connection
example
