4.2 Master Side Setting
B4-33
ME0384-4A
Startup Section
Chapter 4 Network Configuration
Enter the "total module connected" to the CC-Link master.
Set the "leading I/O number".
Next, we set the "I/O leading No." to be assigned to each unit connected to the master unit.
Set according to your context. In this case, we will set it as below.
"Network parameters" screen
X 100
Y 100
D 200
D 100
CC-Link network parameters setting screen
Since there are two units connected to the
CC-Link master in the above connection
example, enter "2" for "total module connected".
Master unit
Units connected to the master
= 2
