6.1 Parameter
B6-31
ME0384-4A
[Lead Size of Ball Screw (Parameter No. 77)]
No. Name Unit Input range
Default initial value setting
77 Ball screw lead length mm 0.01 to 999.99 In accordance with actuator
Sets ball screw lead length.
A value suited to the actuator characteristics is set at shipment.
Caution
● Changing the setting will not only make operation at the instructed speed,
acceleration/deceleration or travel distance impossible but also cause an alarm or
malfunction to occur.
[Axis Motion Type (Parameter No. 78)]
No. Name Unit Input range
Default initial value setting
78 Axis motion type －
0: Linear axis
1: Rotary axis
In accordance with actuator
Sets the type of actuator to use.
Connecting actuator Set value Remarks
Linear axis 0 Actuator other than rotary type
Rotary axis 1 Rotary type actuator
Caution
● Do not attempt to change the setting. This may lead to alarms or malfunctions.
