6.1 Parameter
B6-52
ME0384-4A
[Actuator Recognition Function (parameter No. 192)]
No. Name Unit Input range
Default initial value
setting
192
Actuator recognition
function
－
0: Disabled
1: Enabled
In accordance with actuator
Selects whether to use the actuator information management function or not.
Select "0" when connecting an actuator not compatible with the actuator information
management function or when not using this function.
When an actuator not compatible with the actuator information management function is
connected, the alarm code 0A1 "Parameter data error" occurs when this parameter is "1".
For details, refer to "3.10 Actuator Information Management Function (page A3-180)".
[JOG Switch (Parameter No. 194)]
No. Name Unit Input range
Default initial value setting
194 JOG switch
－
0: Enabled
1: Disabled
0 (Enabled)
Either Enabled or Disabled can be selected for the JOG switch on the front of the driver unit.
When Disabled is selected with this parameter, the actuator does not operate even if the JOG
switch is operated.
* Selection of activation / deactivation of the jog switch on the EC connection unit should be
made in the gateway parameter setting tool.
Refer to “Specifications Section 3.9 Gateway Parameter Configuration Tool / Special
parameter setting function descriptions (Page A3-156)” for detail.
AC servo motor specification and
stepper motor specification only
To Next Page
