IAI Rcon User Manual

2.3 Specifications
A2-14
ME0384-4A
Chapter 2 System Configuration and Specifications
Specifications Section
For the 200V driver unit, the restriction regarding the motor power supply is as described below.
Item Total of Max. Connected Axes Output
3-Phase AC200V 2,400W
Single-Phase AC200V 1,600W
For the 24V system, based on the RCON system configuration, make sure for each unit that the
calculated result for control power and motor power does not exceed the current limit value for
selection calculation.
Note that the gateway unit is not included in the calculations.
For the 200V system, confirm that the total motor wattage on the connected actuators would not
exceed the limit of the calculation for selection.
For the actuators below, calculate with the motor wattage for calculation
Actuator Model Number
Motor Wattage for
Calculation
RCS3-CTZ5 120W
LSA-S6S□/S8S□/S8H□/N10S□ 300W / 1 slider
LSA-S10SM/H8SM/H8HM/L15SM/N15SM/N15HM/N19SM 400W / 1 slider
LSA-S10SS/S10HS/H8SS/H8HS/L15SS/N15SS/N15HS/N19SS 600W
LSA-W21S□, RCS3-CT8 800W / 1 slider
Calculation examples are shown below.
[Control power] * The gateway unit is not included in the calculations.
Ex. 1
24V System Actuator × 16-Axis, All Axes Equipped with Brake (2 axes/unit)
24V Driver Unit (Equipped with Brake) 0.6A × 8＝4.8A ⇒ OK
Ex. 2
24V System Actuator × 16-Axis, All Axes Equipped with Brake (1 axes/unit)
24V Driver Unit (Equipped with Brake) 0.4A × 16＝6.4A ⇒ OK
Ex. 3
24V System Actuator × 8-Axis, All Axes Equipped with Brake (1 axes/unit), All Axes
Simple Absolute
24V Driver Unit (Equipped with Brake) 0.4A × 8 ＋ Simple Absolute 0.2A × 8 ＝ 4.8A ⇒ OK
Ex. 4
200V System Actuator × 8-Axis, All Axes Equipped with Brake
200V Driver Unit (Equipped with Brake) 0.5A × 8＝4.0A ⇒ OK
Ex. 5
24V System Actuator × 7-Axis, All Axes Equipped with Brake (1 axes/unit) , All Axes
Simple Absolute
200V System Actuator × 1-Axis, All Axes Equipped with Brake
EC Connection Unit × 1 unit, SCON Extension Unit × 1 unit
24V Driver Unit (Equipped with Brake) 0.4A × 7＋Simple Absolute 0.2A × 7 +
200V Driver Unit (Equipped with Brake)0.5A×1 +
EC Connection Unit 0.1A × 1 + SCON Extension Unit 0.1A × 1＝4.9A
⇒
OK
Ex. 6
24V System Actuator × 16-Axis, All Axes Equipped with Brake (1 axes/unit), All Axes
Simple Absolute
24V Driver Unit (Equipped with Brake) 0.4A × 16 ＋ Simple Absolute 0.2A × 16 ＝ 9.6A ⇒ NG
