IAI Rcon User Manual

2.3 Specifications
A2-13
ME0384-4A
Specifications Section
Chapter 2 System Configuration and Specifications
[ELECYLINDER Motor Power Supply]
Item
Actuator /EC Connection Unit
Rated
Current
Max.
current
Series Motor type Type
Motor Current
Amperage (for 1
axis of actuator)
Pulse Motor
/RCON-EC
EC
35P/42P/56P
When Power Saving
Setting Invalid
2.3A 3.9A
When Power Saving
Setting Valid
－ 2.2A
28P
S3□/RR3□Type
－
2.2A
Slim and Small Type
－
2.0A
[200V Driver Unit Motor Power Supply]
Wattage of Actuator Motor Motor power capacity [VA]
Transient Max. Motor Current
Amperage [VA]
60 138 414
60 (RCS3-CTZ5) 197 591
100 234 702
100S (LSA) 283 851
150 328 984
200 421 1263
200S (DD) 503 1509
200S (Other LSA (S) - N15H) 486 1458
200S (LSA (S) - N15H) 773 2319
300S (LSA) 662 1986
400 920 2760
400 (RCS3-CT8) 1230 3690
600 1164 2328
600 (DD) 1462 4386
750 1521 3042
750S 1521 4563
The current limit values used for selection calculation are listed below.
Item Current limit values for selection calculation
Control power (CP) 9.0A or less
Motor power (MP) 37.5A or less
