IAI Rcon User Manual

2.5 Connection Diagrams
A2-44
ME0384-4A
Chapter 2 System Configuration and Specifications
Specifications Section
[Simple Absolute Unit Wiring]
Driver cable connector (CONT)
Actuator connector (MPG)
CB-ADPC-MPA005
(Supplied with Simple Absolute Unit)
RCON System
Actuator
Driver unit
For the wiring of this section,
refer to the RCON connection
cable list
on the next page.
Simple Absolute Unit
