2.5 Connection Diagrams
A2-48
ME0384-4A
Chapter 2 System Configuration and Specifications
Note 1: The cable length from each driver unit to actuators should be 30m at maximum.
Note2: When it is required to operate an actuator equipped with a limit switch, it should be the cable
equipped with a limit switch. (It has a limit switch built inside.)
[EC Connection Unit Cable (Common for All Types)]
Standard Connector Cable Code : CB-REC-PWBIO□□□-RB
4-way Connector Cable Code : CB-REC2-PWBIO□□□-RB
*The cable lengths should be 1m at shortest and 10m at longest. Order can be made in every 1m
of length.
*Shown below is an example for the model types.
Cable Length 1ｍ → CB-REC-PWBIO010-RB
Cable Length 3ｍ → CB-REC-PWBIO030-RB
Cable Length 10ｍ → CB-REC-PWBIO100-RB
To Next Page
