Configure:
Save/Restore
Use
this
menu
item
to
restore
the
factory
default
settings.
Figure
80.
Pound
sign
(#)
shows
accessible
menus
when
access
PIN
is
enabled
but
before
it
is
entered
Configure
Save/Restore
a77ug045
Restore
All
Restore Library Config.
Restore Passwords
Save Library Config.
Figure
81.
Configure:
Save/Restore
menu
Operations
105
132
134
