Product description
The IBM TS3100 Tape Library (2U library) and the IBM TS3200 Tape Library (4U library) provide
compact, high-capacity, low-cost solutions for simple, unattended data backup. The 4U library houses up
to 48 tape cartridges (or 45 and an elective 3-slot I/O station) in a compact 4U form factor with easy
access to cartridges by way of four removable magazines. The 2U library houses up to 24 tape cartridges
(or 23 and an elective 1-slot I/O station) in a compact 2U form factor with easy access to cartridges by
way of two removable magazines.
The eighth generation of the Ultrium series of products is available with interfaces to suit your needs: a
Fibre Channel interface (FC), or Serial Attached SCSI interface (SAS), for 2U and 4U libraries. LTO 8
half-height drives are supported.
Front panel
Table 6 on page 2 contains front panel descriptions for both the 2U library in Figure 1 and the 4U library
in Figure 2.
a77ug006
3
1 2
3
44
5
7
8
6
Figure 1. Front panel of a 2U library
a77ug115
1 2
33
4
5
7 6
8
Figure 2. Front panel of a 4U library
