Supported cartridges include:
v IBM LTO8 12 TB Data Cartridge
v IBM LTO M8 9 TB Data Cartridge
v IBM LTO7 6 TB Data Cartridge
v IBM LTO6 2.5 TB Data Cartridge
v IBM LTO5 1.5 TB Data Cartridge
v IBM LTO4 800 GB Data Cartridge
v IBM LTO3 400 GB Data Cartridge
v IBM Write-Once-Read-Many WORM Data Cartridge (Ultrium 3 and later)
v IBM LTO2 200 GB Data Cartridge
v IBM LTO1 100 GB Data Cartridge (read only)
v IBM LTO Ultrium Cleaning Cartridge
Important: Cartridges placed in the library must be labeled with the correct bar code labels. For
information, see “Ultrium media” on page 163.
Library specifications
Physical specifications
Table 10. Physical specifications
Specification 2U library 4U library
Height
Rack mount 87.6 mm (3.44 in),
stand-alone 97.6 mm (3.84 in)
Rack mount 175.2 mm (6.9 in),
stand-alone 185.2 mm (7.3 in)
Width 447.5 mm (17.6 in.) 447.5 mm (17.6 in.)
Depth
Rack mount 740 mm (29.13 in),
stand-alone 810 mm (31.9 in)
Rack mount 740 mm (29.13 in),
stand-alone 810 mm (31.9 in)
Weight with 1 drive and without
media 15.59 kg (34.37 lbs.) 21.32 kg (47 lbs.)
Weight with media 20.67 kg (45.57 lbs.) 31.71 kg (69.9 lbs.)
Power specifications
Table 11. Power specifications
AC power voltage 100-127 VAC; 200-240 VAC (4 - 2 A)
Line frequency 50-60 Hz
Operation specifications
Table 12. Operation specifications: Ultrium 8
Library with
Ultrium 8 drive(s)
2U Library 4U Library
Maximum storage
capacity
Maximum number of data cartridges: 24
Native:
- 288 TB using LTO Ultrium 8 cartridges
- 216 TB using LTO M8 cartridges
Compressed (2.5:1 compression):
- 720 TB using LTO Ultrium 8 cartridges
- 540 TB using LTO M8 cartridges
Maximum number of data cartridges: 48
Native:
- 576 TB using LTO Ultrium 8 cartridges
- 432 TB using LTO M8 cartridges
Compressed (2.5:1 compression):
- 1440 TB using LTO Ultrium 8 cartridges
- 1080 TB using LTO M8 cartridges
12 IBM TS3100 Tape Library and TS3200 Tape Library: Setup, Operator, and Service Guide Machine Type 3573
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
