IBM TS3100 Service Manual

Table 6. 2U library and 4U library front panel descriptions (continued)
Number Item Description
▌7▐ Operator Control Panel display This component is a 128 X 64 monochrome graphic
display.
▌8▐ I/O station The input/output (I/O) station is used to import and
export cartridges into and out of the library.
v The 2U library has an elective 1-slot I/O station.
v The 4U library has an elective 3-slot I/O station.
Rear panel
1
2
3
a77ug300
Figure 3. Rear panel (drive sled only) of a half height Fibre Channel drive
a77ug233
1
3
4
12
5
6
7
8
10
2
11
9
Figure 4. Rear panel of a 4U library with full height Fibre Channel drive and half height SAS drives.
Product description 3
