Table 65. Library Sense Keys, ASC and ASCQ (continued)

Sense Key ASC ASCQ Description

Not Ready (02) 00h 17h Drive cleaning requested

04h 00h Cause not reportable

04h 01h In progress becoming ready, scanning magazines, etc.

04h 02h Initializing command required

04h 03h Manual intervention required

04h 07h Operation in progress

04h 12h Offline

04h 83h Door open

04h 85h Firmware upgrade in progress

04h 87h The drive is not enabled

04h 88h The drive is busy

04h 89h The drive is not empty

04h 9Ah Drive fibre down

04h 8Eh The media changer is in sequential mode

30h 03h Cleaning in progress

3Bh 12h Magazine removed

04h 8Fh No free storage slots

Medium Error (03) 30h 00h Incompatible media installed

30h 03h Cleaning tape installed

30h 07h Cleaning failure

298 IBM TS3100 Tape Library and TS3200 Tape Library: Setup, Operator, and Service Guide Machine Type 3573
