IBM TS3100 Service Manual

Table 15. Operation specifications: Ultrium 5
Library with
Ultrium 5 drive(s)
2U Library 4U Library
Maximum storage
capacity
Maximum number of data cartridges: 24
Native: 36 TB
Compressed: 72 TB (2:1 compression)
Maximum number of data cartridges: 48
Native: 72 TB
Compressed: 144 TB (2:1 compression)
Number of slots 24 (including I/O station) 48 (Including 3 I/O station slots)
Sustained native
data transfer rate
Ultrium 5 Full Height Drive: 140 MB/s
Ultrium 5 Half Height Drive: 140 MB/s
Drive types
Ultrium 5 Full Height Drive:
Fibre Channel, SAS
Ultrium 5 Half Height Drive:
Fibre Channel, SAS
Interfaces
8 Gb/s Fibre Channel
6 Gb/s SAS
*Host Interface Drive Transfer Rates may vary depending on host usage and interface utilization.
Table 16. Operation specifications: Ultrium 4
Library with
Ultrium 4 drive(s)
2U Library 4U Library
Maximum storage
capacity
Maximum number of data cartridges: 24
Native: 19.2 TB
Compressed: 38.4 TB (2:1 compression)
Maximum number of data cartridges: 48
Native: 38.4 TB
Compressed: 75.2 TB (2:1 compression)
Number of slots 24 (including I/O station) 48 (Including 3 I/O station slots)
Sustained native
data transfer rate
Ultrium 4 Full Height Drive: 120 MB/s
Ultrium 4 Half Height Drive: 120 MB/s
Drive types
Ultrium 4 Full Height Drive:
SCSI, Fibre Channel, SAS
Ultrium 4 Half Height Drive: SAS, Fibre Channel
Interfaces
Ultrium 4 HH Fibre Drive V2 (8 Gb/s)
Ultrium 4 HH SAS Drive V2 (6 Gb/s)
Ultra160 SCSI LVD
4 Gb/s Fibre Channel
3 Gb/s SAS
*Host Interface Drive Transfer Rates may vary depending on host usage and interface utilization.
Table 17. Operation specifications: Ultrium 3
Library with
Ultrium 3 drive(s)
2U library 4U library
Maximum storage
capacity
Maximum number of data cartridges: 24
Native: 9.6 TB
Compressed: 19.2 TB (2:1 compression)
Maximum number of data cartridges: 48
Native: 19.2 TB
Compressed: 38.4 TB (2:1 compression)
Number of slots 24 (including I/O station) 48 (Including 3 I/O station slots.)
Sustained native
data transfer rate
Ultrium 3 Full Height Drive: 80 MB/s
Ultrium 3 Half Height V2 Drive: 80 MB/s
Ultrium 3 Half Height Drive: 60 MB/s
Drive types
Ultrium 3 Full Height
Drive: SCSI, Fibre Channel
Ultrium 3 Half Height Drive: SCSI, Serial Attached SCSI (SAS)
14 IBM TS3100 Tape Library and TS3200 Tape Library: Setup, Operator, and Service Guide Machine Type 3573
